PL19J133 Ch= 15G1B
ID = 140117
 |
 |
 |
 |
 |
Admiral brand : PL19J133 Ch= 15G1B [Television] ID = 525326 765x700
| Country: United States of America (USA) | Manufacturer/Brand: Admiral (brand) Continental Radio & Television Co. |
| Year: 1959 ? | Type: Television Receiver (TV) |
| Valves / Tubes | 14: 3BZ6 3DK6 6AW8A 3BU8 3DT6 12CU5 10DE7 6CG7 12DQ6A 12AX4GTA 1G3GT 2CY5 5CG8 19XP4 |
|---|
| Principle | not available |
|---|---|
| Wave bands | Wave Bands given in the notes. |
| Power type and voltage | Alternating Current supply (AC) / 110 - 120 Volt |
| Loudspeaker/pwr.out | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical |
| from Radiomuseum.org | Model: PL19J133 Ch= 15G1B |
| Shape | Tablemodel, with any shape - general. |
| Notes | Channels 2 thru 13 VHF, 14 thru 83 UHF, video IF 45,75 mc. Sams photofact set 501 folder 1 date 10-60 features the Admiral models PL19J131, PL19J133, PL19J135, PL19J141, PL19J149 with chassis 15G1B and the models PL19UJ131, PL19UJ133, PL19UJ135, PL19UJ140, PL19UJ141 and PL19UJ149 with chassis 15UG1B as the same schematic. |
This model was suggested by Peter Hoddow.
