Stereo Cassette Deck AD-WX777

Aiwa Co. Ltd.; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1989
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 284551

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Alternating Current supply (AC) / 120 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Stereo Cassette Deck AD-WX777 - Aiwa Co. Ltd.; Tokyo
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 430 x 140 x 313 mm / 16.9 x 5.5 x 12.3 inch
  • Notes

  • Aiwa Frontloading Double Cassette Deck Model AD-WX777.
    Track System: 4-track, 2-channel stereo
    Tape Speed: 4.8, 9.5 cm/s
    Heads: 1 x record/playback, 1 x playback, 1 x erase
    Motor: 2 x DC servo
    Tape Type: type I, Cr02, Metal
    Noise Reduction: Dolby B, C
    Frequency Response: 20Hz to 18000 Hz (Metal tape)
    Signal to Noise Ratio: 73dB (dolby C)
    Wow and Flutter: 0.065%
    Input: 50mV (line)
    Output: 360V (line)
    A.M.T.S. - Anti-Modulation Tape Stabilizer
    Double Quick Auto Reverse
    Continuous Playback
    Bias Fine Adjustor (+/-20%)
    IC logic feather-touch controls
    High Speed Dubbing
    Power Consumption 23 Watts

  • Net weight (2.2 lb = 1 kg)
  • 5.2 kg / 11 lb 7.3 oz (11.454 lb)
  • Mentioned in
  • - - Manufacturers Literature (Service Manual)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
