Knight R.F. Generator - Signal KG-686

Knight R.F. Generator - Signal KG-686; Allied Radio Corp. (ID = 1274558) Equipment Knight R.F. Generator - Signal KG-686; Allied Radio Corp. (ID = 1275509) Equipment
Use red slider bar for more.
Knight R.F. Generator - Signal KG-686; Allied Radio Corp. (ID = 1274558) Equipment
Allied Radio Corp.: Knight R.F. Generator - Signal KG-686 [Equipment] ID = 1274558 716x432
Select picture or schematic to display from thumbnails on the right and click for download.
For model Knight R.F. Generator - Signal KG-686, Allied Radio Corp. (Knight, Roamer, Wextark); Chicago (IL)

Country:  United States of America (USA)
Manufacturer / Brand:  Allied Radio Corp. (Knight, Roamer, Wextark); Chicago (IL)
Year: 1975 ?? Type: Service- or Lab Equipment
Semiconductors (the count is only for transistors) 10:
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 cm = 2 inch
Power out 0.1 W (unknown quality)
from Radiomuseum.org Model: Knight R.F. Generator - Signal KG-686 - Allied Radio Corp. Knight,
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 370 x 180 x 222 mm / 14.6 x 7.1 x 8.7 inch
Notes Signal Generator for CW and AM, 5 bands:
100-370 kHz, 370-1400 kHz, 1,4-5,1 MHz, 5,1-16 MHz, 16-54 MHz.
Included 1 MHz and 100 kHz quartz calibration generator.
Internal modulation at 420 Hz. External modulation input.
Calibrated output RF attenuator.
Built-in loudspeaker.
Net weight (2.2 lb = 1 kg) 5 kg / 11 lb 0.2 oz (11.013 lb)

Model page created by Alberto Sanna-Alonso. See "Data change" for further contributors.
