Knight RF Signal Generator KG-650

Knight RF Signal Generator KG-650; Allied Radio Corp. (ID = 965979) Equipment
Use red slider bar for more.
Knight RF Signal Generator KG-650; Allied Radio Corp. (ID = 965979) Equipment
Allied Radio Corp.: Knight RF Signal Generator KG-650 [Equipment] ID = 965979 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model Knight RF Signal Generator KG-650, Allied Radio Corp. (Knight, Roamer, Wextark); Chicago (IL)

Country:  United States of America (USA)
Manufacturer / Brand:  Allied Radio Corp. (Knight, Roamer, Wextark); Chicago (IL)
Year: 1959 ?? Type: Service- or Lab Equipment
Valves / Tubes 2: 6C4 12AT7
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Knight RF Signal Generator KG-650 - Allied Radio Corp. Knight,
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 255 x 180 x 130 mm / 10 x 7.1 x 5.1 inch
Notes Knight R.F.-Generator KG-650;
Coverage: 160 kHz - 112 MHz in five bands.
Band A: 160...550 kHz
Band B: 550...1850 kHz
Band C: 1.8...7.2 MHz
Band D: 7.0...27.5 MHz
Band E: 27...112 MHz
Output attenuator: course (3-step HI-MED-LO) and fine.
Modulation: intern and extern, adjustable modulation gain.
Net weight (2.2 lb = 1 kg) 2.2 kg / 4 lb 13.5 oz (4.846 lb)
Collectors' prices
Source of data - - Data from my own collection

Model page created by Alberto Sanna-Alonso. See "Data change" for further contributors.
