• Year
  • 1932
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 165181

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 4
  • Main principle
  • TRF with regeneration; 1 AF stage(s); Anode bend detection
  • Tuned circuits
  • 2 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Alternating Current supply (AC)
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Radiola Junior Ch= C87 - Amalgamated Wireless
  • Shape
  • Console, Lowboy (legs < 50 %).
  • Notes
  • Uses same chassis (C87) as 1932 Radiolette.

    According to the AWA Service Data 1932, a later modification was to change the RF Choke to a centre tapped version with two extra filter capacitors added.

  • Price in first year of sale
  • 25.00 Aus£
  • Literature/Schematics (1)
  • AWA Service Data 1932, Page 18
  AWA Radiola Junior Pamphlet. 619 KB
