• Country
• Switzerland

• Manufacturer / Brand
• Autophon AG (inkl. Téléphonie SA); Solothurn

• Year
• 1938/1939

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 11333

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 10

• Valves / Tubes
• EF5 EK2 EF5 EB4 EM1 AC2 AC2 AD1 AD1 EZ4

• Main principle
• Superhet with RF-stage; ZF/IF 471 kHz

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and 2 x Short Wave.

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 110-250 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Royal Combinaton - Combination - Autophon AG inkl. Téléphonie

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 620 x 999 x 490 mm / 24.4 x 39.3 x 19.3 inch

• Notes
• Das Standgerät Autophon Royal Combination ist mit 2 elektrodynamischen
  Lautsprechern (Tiefton und Mittel-Hochton) ausgestattet.
  100/RD2719d, mit TR.

• External source of data
• E. Erb 3-907007-36-0

• Source of data
• Radiokatalog Band 2, Ernst Erb
