AC 636 Senior

AC 636 Senior; Barco, Belgian (ID = 1782837) Radio AC 636 Senior; Barco, Belgian (ID = 1283353) Radio
AC 636 Senior; Barco, Belgian (ID = 309953) Radio AC 636 Senior; Barco, Belgian (ID = 309954) Radio
AC 636 Senior; Barco, Belgian (ID = 1283350) Radio AC 636 Senior; Barco, Belgian (ID = 1283351) Radio
AC 636 Senior; Barco, Belgian (ID = 1283352) Radio AC 636 Senior; Barco, Belgian (ID = 1787281) Radio
AC 636 Senior; Barco, Belgian (ID = 2023570) Radio
Use red slider bar for more.
AC 636 Senior; Barco, Belgian (ID = 1782837) Radio
Barco, Belgian: AC 636 Senior [Radio] ID = 1782837 933x1161
Select picture or schematic to display from thumbnails on the right and click for download.
For model AC 636 Senior, Barco, Belgian American Radio Corporation / Cobar; Poperinge

Country:  Belgium
Manufacturer / Brand:  Barco, Belgian American Radio Corporation / Cobar; Poperinge
Year: 1935/1936 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6D6 6A7 6D6 75 42 80
Main principle Superhet with RF-stage
Tuned circuits 10 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out 3 W (unknown quality)
from Radiomuseum.org Model: AC 636 Senior - Barco, Belgian American Radio
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 430 x 560 x 340 mm / 16.9 x 22 x 13.4 inch
Notes

Sélectivité 9 Kc. Triple condensateur. Antifading, AVC. Sensibilité et tonalité réglable.

Mentioned in -- Original prospect or advert

Model page created by Stefan Klumpp. See "Data change" for further contributors.



All listed radios etc. from Barco, Belgian American Radio Corporation / Cobar; Poperinge
Here you find 47 models, 43 with images and 9 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
