Minitel 43-NB

Minitel 43-NB; Biennophone; Marke (ID = 233276) Radio Minitel 43-NB; Biennophone; Marke (ID = 753060) Radio
Minitel 43-NB; Biennophone; Marke (ID = 753061) Radio Minitel 43-NB; Biennophone; Marke (ID = 753062) Radio
Minitel 43-NB; Biennophone; Marke (ID = 753063) Radio
Use red slider bar for more.
Minitel 43-NB; Biennophone; Marke (ID = 233276) Radio
Biennophone; Marke: Minitel 43-NB [Radio] ID = 233276 933x616
Select picture or schematic to display from thumbnails on the right and click for download.
For model Minitel 43-NB, Biennophone; (Marke)

Country:  Switzerland
Manufacturer / Brand:  Biennophone; (Marke)
alternative name

Sport AG Biel || Velectra AG
Year: 1981–1985 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle TRF with diode detector
Wave bands Long Wave and/or Very Low Frequency (VLF).
Details Wired Wireless Receiver (RF!)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Minitel 43-NB - Biennophone; Marke
Material Wooden case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 198 x 115 x 130 mm / 7.8 x 4.5 x 5.1 inch
Notes 6 Fixtasten für den Telefonrundspruchempfang.
Price in first year of sale 345.00 SFR
Collectors' prices
Source of data - - Data from my own collection

Model page created by Markus Meier. See "Data change" for further contributors.



All listed radios etc. from Biennophone; (Marke)
Here you find 493 models, 267 with images and 300 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
