Mürren 60 6005

Mürren 60 6005; Biennophone; Marke (ID = 37842) Radio
Mürren 60 6005; Biennophone; Marke (ID = 249350) Radio Mürren 60 6005; Biennophone; Marke (ID = 237978) Radio
Mürren 60 6005; Biennophone; Marke (ID = 237979) Radio Mürren 60 6005; Biennophone; Marke (ID = 1451) Radio
Mürren 60 6005; Biennophone; Marke (ID = 249351) Radio
Use red slider bar for more.
Mürren 60 6005; Biennophone; Marke (ID = 249350) Radio
Biennophone; Marke: Mürren 60 6005 [Radio] ID = 249350 933x676
Select picture or schematic to display from thumbnails on the right and click for download.
For model Mürren 60 6005, Biennophone; (Marke)

Country:  Switzerland
Manufacturer / Brand:  Biennophone; (Marke)
alternative name

Sport AG Biel || Velectra AG
Year: 1960 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EF89 EABC80 EM84 EL84 EZ80
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Mürren 60 6005 - Biennophone; Marke
Material Wooden case
Dimensions (WHD) 440 x 275 x 215 mm / 17.3 x 10.8 x 8.5 inch
Notes eckig, 6 Tasten; plus TR
Price in first year of sale 375.00 SFr
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.


All listed radios etc. from Biennophone; (Marke)
Here you find 493 models, 267 with images and 300 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
