• Year
  • 1956/1957 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 171838
    • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
    • Brand: Rotstern

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 7
  • Number of Transistors
  • Main principle
  • Superhet with RF-stage; ZF/IF 460/10700 kHz
  • Tuned circuits
  • 7 AM circuit(s)     12 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 127; 155; 220; 240 Volt
  • Loudspeaker
  • 5 Loudspeakers
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Arkansas Ch= 2340 - Blaupunkt Ideal, Berlin,
  • Shape
  • Console with Push Buttons.
  • Notes
  • Receiver chassis = Barcelona 2340 USA

    The Blaupunkt Model Arkansas is an AC operated 7 Tube FM-BC-SW-LW Receiver.
    Importer: N. Pickens Import Co., 64-01 Woodside Ave., N. Y.

  • Author
  • Model page created by Egon Penker. See "Data change" for further contributors.
