• Country
• Germany

• Manufacturer / Brand
• Blaupunkt (Ideal), Berlin, später Hildesheim

• Year
• 1977/1978

• Category
• Citizen Band Equipment

• Radiomuseum.org ID
• 125691

• • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
  • Brand: Rotstern

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 25

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Short Wave (SW only)

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 5 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: CB-Mobilfunkgerät CB1000 7.647.020.010 - Blaupunkt Ideal, Berlin,

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 180 x 43 x 185 mm / 7.1 x 1.7 x 7.3 inch

• Notes

• CB-Funkgerät für den 27-MHz-Bereich mit 12 Kanälen (4 bis15), AM Modulation und 0,5 W HF-Ausgangsleistung, digitale Kanalanzeige, LED-Feld für RX/TX.

  Geeignet für den Einbau in den normalen Autoradio-Schacht oder in der Blaupunkt CB Station 1000

• Net weight (2.2 lb = 1 kg)
• 1 kg / 2 lb 3.2 oz (2.203 lb)

• Source of data
• Handbuch VDRG 1977/1978

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
