Köln ab K 180001; Blaupunkt Ideal (ID = 1036687) Car Radio
Blaupunkt Ideal: Köln ab K 180001 [Car Radio] ID = 1036687 800x388
Select picture or schematic to display from thumbnails on the right and click for download.
For model Köln ab K 180001, Blaupunkt (Ideal):
Dieses Bild stammt aud dem original Kundendienstmanual.

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal)
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1956/1957 Type: Car Radio
Valves / Tubes 7: ECC85 EF89 ECH81 EBF89 EABC80 ECC85 EL84
Semiconductors (the count is only for transistors) RL232 RL232 Tr.Gl.=Metal-rectif.
Principle Superhet with RF-stage; ZF/IF 460/10700 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave and FM.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 3 W (unknown quality)
from Radiomuseum.org Model: Köln ab K 180001 - Blaupunkt Ideal
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 183 x 76 x 168 mm / 7.2 x 3 x 6.6 inch
Notes Blaupunkt Köln mit Sendersuchlauf "Selectomat Stationsfinder".
Maße Stromversorgungsteil m. Endstufe: 187 x 117 x 73 mm, Gewicht: 2,6 kg.
Net weight (2.2 lb = 1 kg) 3 kg / 6 lb 9.7 oz (6.608 lb)
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Bernd Urban. See "Data change" for further contributors.
