Sultan 24300
ID = 25611
 |
 |
 |
 |
 |
 |
 |
 |
 |
Blaupunkt Ideal: Sultan 24300 [Radio] ID = 497076 933x545
|
|
||||
|
alternative name
|
 |
||||
|---|---|---|---|---|---|
Brand |
Rotstern | ||||
| Year: 1964/1965 | Type: Radio - or past WW2 tuner | ||||
| Valves / Tubes | 5: ECC85 ECH81 EAF801 ECL86 EM87 |
| Principle | Super-Heterodyne (Super in general); IF-Freq 460/10700 kHz |
|---|---|
| Tuned circuits | 6 AM circuit(s) 10 FM circuit(s) |
| Wave bands | Broadcast, Long Wave, Short Wave plus FM. |
| Details | |
| Power type and voltage | Alternating Current supply (AC) / 110; 127; 155; 220 Volt |
| Loudspeaker | 3 Loudspeakers |
| Power out | 4 W |
| from Radiomuseum.org | Model: Sultan 24300 - Blaupunkt Ideal |
| Material | Wooden case |
| Shape | Tablemodel with Push Buttons. |
| Dimensions (WHD) | 505 x 310 x 215 mm / 19.9 x 12.2 x 8.5 inch |
| Notes | Dioden: 2× AA113 |
| Net weight (2.2 lb = 1 kg) | 8.2 kg / 18 lb 1 oz (18.062 lb) |
| Price in first year of sale | 470 DM |
| Collectors' prices | 3 Collector prices (for members Radiomuseum.org) |
| External source of data | Erb |
| Source of data | Handbuch VDRG 1964 / |
