W- 400 Export Point-Bleu

W- 400 Export Point-Bleu; Blaupunkt Ideal, (ID = 553721) Radio W- 400 Export Point-Bleu; Blaupunkt Ideal, (ID = 553723) Radio
W- 400 Export Point-Bleu; Blaupunkt Ideal, (ID = 736833) Radio W- 400 Export Point-Bleu; Blaupunkt Ideal, (ID = 736835) Radio
W- 400 Export Point-Bleu; Blaupunkt Ideal, (ID = 736836) Radio W- 400 Export Point-Bleu; Blaupunkt Ideal, (ID = 736837) Radio
W- 400 Export Point-Bleu; Blaupunkt Ideal, (ID = 736838) Radio W- 400 Export Point-Bleu; Blaupunkt Ideal, (ID = 736840) Radio
W- 400 Export Point-Bleu; Blaupunkt Ideal, (ID = 736842) Radio
Use red slider bar for more.
W- 400 Export Point-Bleu; Blaupunkt Ideal, (ID = 553721) Radio
Blaupunkt Ideal,: W- 400 Export Point-Bleu [Radio] ID = 553721 933x532
Select picture or schematic to display from thumbnails on the right and click for download.
For model W- 400 Export Point-Bleu, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1931–1933 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: RENS1204 RENS1204 or REN904 RENS1204 RE304 RGN1054
Main principle TRF with regeneration; Screengrid 1926-1935
Tuned circuits 2 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110 - 240 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: W- 400 Export Point-Bleu - Blaupunkt Ideal, Berlin,
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 465 x 260 x 215 mm / 18.3 x 10.2 x 8.5 inch
Notes entspricht id= 497.

Model page created by Museum: Radiomuseum Olen. See "Data change" for further contributors.



All listed radios etc. from Blaupunkt (Ideal), Berlin, später Hildesheim
Here you find 3061 models, 2699 with images and 2092 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
