Handfunkgerät HFG 161 X 20/1
 |
 |
 |
 |
Use red slider bar for more.
Bosch; Deutschland: Handfunkgerät HFG 161 X 20/1 [TRX] ID = 1136932 933x594
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1972 | Type: Transmitter & Receiver (TRX not Amateur) | ||||
| Semiconductors (the count is only for transistors) | Semiconductors present. |
|---|
| Principle | Transceiver |
|---|---|
| Wave bands | VHF/UHF (see notes for details) |
| Details | |
| Power type and voltage | Storage Battery for all / 12 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 cm = 2 inch |
| Power out | |
| from Radiomuseum.org | Model: Handfunkgerät HFG 161 X 20/1 - Bosch; Deutschland |
| Material | Modern plastics (no Bakelite or Catalin) |
| Shape | Very small Portable or Pocket-Set (Handheld) < 8 inch. |
| Dimensions (WHD) | 80 x 220 x 50 mm / 3.1 x 8.7 x 2 inch |
| Notes | Handfunkgerät für Betriebsfunk im 2 m-Band (146 bis 174 MHz). Es gibt auch Versionen des HFG 161 für das 0,7 m- und das 4 m-Band. 10 Kanäle schaltbar, Quarzsteuerung (1 Quarz je Kanal). Frequenzmodulation, Tonruf. FTZ-Nr.: E-233/72 |
| Net weight (2.2 lb = 1 kg) | 0.7 kg / 1 lb 8.7 oz (1.542 lb) |
Model page created by Siegfried Droese. See "Data change" for further contributors.
