• Year
  • 1953
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 93599

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common); ZF/IF 470 kHz
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Line / Batteries (any type) / 200-250; (90; 7.5) Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6.5 inch = 16.5 cm
  • Power out
  • 0.15 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: BAC31 - Bush Radio; London
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 13.25 x 11 x 8 inch / 337 x 279 x 203 mm
  • Notes
  • uses Ever Ready B107 (90 volts HT) & AD31 (7.5 volts LT) Batteries and Power Unit Type 42. Power unit was an option only for some models.
  • Net weight (2.2 lb = 1 kg)
  • 14 lb 4 oz (14.25 lb) / 6.470 kg
  • Source of data
  • -- Collector info (Sammler)
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
