Detektor-Empfänger DE53

Caesar, R.; Berlin (Ostd.)

  • Year
  • 1952
  • Category
  • Detector-Radio (Crystal or diode, without tubes/transistors)
  • Radiomuseum.org ID
  • 72844

 Technical Specifications

  • Main principle
  • Crystal or Solid State Detector; Crystal-detection 1 circuit (no tubes)
  • Tuned circuits
  • 1 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • No Power needed
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Bakelite case
  • from Radiomuseum.org
  • Model: Detektor-Empfänger DE53 - Caesar, R.; Berlin Ostd.
  • Dimensions (WHD)
  • 60 x 40 x 85 mm / 2.4 x 1.6 x 3.3 inch
  • Notes
  • Ge-Diode, Spule eingebaut.
  • Source of data
  • Radiokatalog Band 2, Ernst Erb
  • Author
  • Model page created by Wolfgang Eckardt. See "Data change" for further contributors.
