- Country
- Canada
- Manufacturer / Brand
- Canadian Marconi Co. Ltd. (CMC, Esterline), Marconi's Wireless; Montreal, QC
- Year
- 1937/1938
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 189045
-
- alternative name: CMC Canada || Marconi, Canada
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 462.5 kHz; 3 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Storage and/or dry batteries
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 106 - Canadian Marconi Co. Ltd. CMC,
- Notes
-
This model 106 is a battery operated radio (shape unknown yet) for storage battery "A" supply, battery "B" supply of 2 x 45 V and an aircell as "C" battery. Careful: Some of those sets have been changed to AC and do not show original wiring etc. The chassis is the same for Canadian Marconi model 106 and 107. The model 107 is a console - but we don't know yet the cabinet of the model 106.
- Literature/Schematics (1)
- Radio College of Canada (RCC) (see also Marconi Service Manual vol.1, 2nd ed., p 197)
- Author
- Model page created by Ernst Erb. See "Data change" for further contributors.
