• Year
  • 1947/1948
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 215378
    • alternative name: CMC Canada || Marconi, Canada

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 8
  • Main principle
  • Superheterodyne (common); ZF/IF 456 kHz; 3 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Details
  • Recording phonogr.-Disc Recorder
  • Power type and voltage
  • Alternating Current supply (AC) / 115 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • from Radiomuseum.org
  • Model: 6B30 - Canadian Marconi Co. Ltd. CMC,
  • Notes
  • The Marconi Model 6B30 is an AC operated 8 Tube combination BC Band Receiver, Disk Recorder with Microphone, Public Address System and phonograph. BC Band Tuning Range: 540 to 1600kHz. Has built-in loop antenna. Uses Qty(1) Elliptical PM 6" x 9" speaker. Built-in record player is not a record changer. Marconi Models 6B10, 6B42 and 6B45 use the same chassis and schematic.
  • Author
  • Model page created by John Kusching. See "Data change" for further contributors.
