- Country
- Canada
- Manufacturer / Brand
- Canadian Marconi Co. Ltd. (CMC, Esterline), Marconi's Wireless; Montreal, QC
- Year
- 1932/1933
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 221702
-
- alternative name: CMC Canada || Marconi, Canada
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superheterodyne (common); ZF/IF 175 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Storage and/or dry batteries / 2 & 90 & 180 & -22.5 Volt
- Loudspeaker
- -Loudspeaker incorporated, but system not known.
- from Radiomuseum.org
- Model: 33 - Canadian Marconi Co. Ltd. CMC,
- Notes
-
Push-pull af output.
- Literature/Schematics (1)
- Marconi Service Manual Volume No. 2
- Literature/Schematics (2)
- Radio College of Canada (RCC) (Marconi data sheet 14)
- Author
- Model page created by Bruce Morgenstern. See "Data change" for further contributors.
