JK-66 Beam-A-Scope

JK-66 Beam-A-Scope ; Canadian General (ID = 198041) Radio

JK-66 Beam-A-Scope ; Canadian General (ID = 198043) Radio
JK-66 Beam-A-Scope ; Canadian General (ID = 992636) Radio JK-66 Beam-A-Scope ; Canadian General (ID = 992638) Radio
JK-66 Beam-A-Scope ; Canadian General (ID = 992639) Radio JK-66 Beam-A-Scope ; Canadian General (ID = 537715) Radio
JK-66 Beam-A-Scope ; Canadian General (ID = 711382) Radio JK-66 Beam-A-Scope ; Canadian General (ID = 992637) Radio
Use red slider bar for more.
JK-66 Beam-A-Scope ; Canadian General (ID = 992636) Radio
Canadian General: JK-66 Beam-A-Scope [Radio] ID = 992636 461x640
Select picture or schematic to display from thumbnails on the right and click for download.
For model JK-66 Beam-A-Scope, Canadian General Electric (Canada) (C.G.E. or CGE)

Country:  Canada
Manufacturer / Brand:  Canadian General Electric (Canada) (C.G.E. or CGE)
Year: 1940/1941 Type: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6SK7 6SA7 6SK7 6SQ7 6F6G 5Y4G
Principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: JK-66 Beam-A-Scope - Canadian General Electric
Material Wooden case
Shape Console with Push Buttons.
Notes The model JK-66 has a Beam-A-Scope antenna built in. A "Beam-A-Scope" is just the own branding for an internal loop antenna, as for instance Zenith called "WaveMagnet". Often the loop is shielded with a wire cage or foil. Sometimes an external antenna coupler is built in. Can be either extra turns on the main coil or a smaller inductor nested within the larger coil. Some can be turned in direction, most can not. Some are very big, like on the model J-1005, others are small. They have to be right to fit the RF circuit.
Source of data Pre-War Consoles; Stein, 2000
Literature/Schematics (1) Radio College of Canada, Individual Circuit Service, 1927-1953

Model page created by Vitor Oliveira. See "Data change" for further contributors.
