• Year
  • 1980–1988 ??
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 104844
    • Brand: Voltcraft

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • from Radiomuseum.org
  • Model: Wobbel-Funktionsgenerator FG1617 - Conrad Electronic Voltcraft,
  • Shape
  • Tablemodel without push buttons, Mantel/Midget/Compact up to 14
  • Dimensions (WHD)
  • 277 x 85 x 236 mm / 10.9 x 3.3 x 9.3 inch
  • Notes
  • Professioneller Funktionsgenerator mit Frequenzzähler und Wobbelfunktion.
    Generator: Sinus, Recheck, Dreieck, TTL, 0,2 Hz bis 2 MHz;
    Wobbelteil: lin/log 0,2 bis 40 Hz bis Bandbreite 1000:1;
    Frequenzzähler: 10 MHz, Eingang 1 MOhm, 40 mVeff, Torzeiten 0,01 s bis 10 s, Genauigkeit ± 10 ppm.
  • Net weight (2.2 lb = 1 kg)
  • 2 kg / 4 lb 6.5 oz (4.405 lb)
  • Price in first year of sale
  • 598.00 DM
  • Mentioned in
  • -- Original-techn. papers.
  • Literature/Schematics (1)
  • Conrad-Katalog 1988, Seite 109
