D-25 11-120

D-25 11-120; Crosley Radio and (ID = 1387743) Radio
D-25 11-120; Crosley Radio and (ID = 415438) Radio D-25 11-120; Crosley Radio and (ID = 415439) Radio
D-25 11-120; Crosley Radio and (ID = 415440) Radio D-25 11-120; Crosley Radio and (ID = 1215928) Radio
D-25 11-120; Crosley Radio and (ID = 1215930) Radio D-25 11-120; Crosley Radio and (ID = 1215932) Radio
D-25 11-120; Crosley Radio and (ID = 1215933) Radio D-25 11-120; Crosley Radio and (ID = 1215934) Radio
D-25 11-120; Crosley Radio and (ID = 1215935) Radio D-25 11-120; Crosley Radio and (ID = 1216732) Radio
Use red slider bar for more.
D-25 11-120; Crosley Radio and (ID = 415438) Radio
Crosley Radio and: D-25 11-120 [Radio] ID = 415438 933x678
Select picture or schematic to display from thumbnails on the right and click for download.
For model D-25 11-120, Crosley Radio and Television Ltd.; Toronto and Moffats, Ontario

Country:  Canada
Manufacturer / Brand:  Crosley Radio and Television Ltd.; Toronto and Moffats, Ontario
Year: 1951 ? Type: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12BE6 12BA6 12AT6 50C5 35W4
Principle Super-Heterodyne (Super in general); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC) / 117 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4.5 inch = 11.4 cm
Power out
from Radiomuseum.org Model: D-25 11-120 - Crosley Radio and Television
Material Moulded (Bakelite or Plastics)
Shape Tablemodel with Clock ((Alarm-) Clock Radio).
Dimensions (WHD) 13.25 x 7.5 x 7 inch / 337 x 191 x 178 mm
Notes Appears to be the same as the US Crosley model D25.
Net weight (2.2 lb = 1 kg) 3.7 kg / 8 lb 2.4 oz (8.15 lb)
Collectors' prices
Source of data - - Data from my own collection
Circuit diagram reference Radio College of Canada
Literature/Schematics (1) Supplement page 26 & 27.

Model page created by Keith Staines. See "Data change" for further contributors.



All listed radios etc. from Crosley Radio and Television Ltd.; Toronto and Moffats, Ontario
Here you find 103 models, 34 with images and 101 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
