Harko Senior (Sr.) Model V-B Regenerative made by Tri-City Electric

Crosley Radio Corp.; Cincinnati (OH)

Data

Forum

Pictures

Collections

Country
United States of America (USA)

Manufacturer / Brand
Crosley Radio Corp.; Cincinnati (OH)

Year
1922/1923

Category
Broadcast Receiver - or past WW2 Tuner

Radiomuseum.org ID
182381

Schematics

Harko Senior Model V-B; Crosley Radio Corp.; (ID = 2715930) Radio — Crosley Radio Corp.; Harko Senior Model V-B (1)
From my collection, photo by me.

Harko Senior Model V-B; Crosley Radio Corp.; (ID = 2715932) Radio — Crosley Radio Corp.; Harko Senior Model V-B (1)
From my collection, photo by me.

Harko Senior Model V-B; Crosley Radio Corp.; (ID = 2715931) Radio — Crosley Radio Corp.; Harko Senior Model V-B (1)
From my collection, photo by me.

Harko Senior Model V-B; Crosley Radio Corp.; (ID = 2715933) Radio — Crosley Radio Corp.; Harko Senior Model V-B (1)
From my collection, photo by me.

Harko Senior Model V-B; Crosley Radio Corp.; (ID = 822046) Radio — Crosley Radio Corp.; Harko Senior Model V-B (1)

Harko Senior Model V-B; Crosley Radio Corp.; (ID = 822050) Radio — Crosley Radio Corp.; Harko Senior Model V-B (1)

Harko Senior Model V-B; Crosley Radio Corp.; (ID = 822051) Radio — Crosley Radio Corp.; Harko Senior Model V-B (1)

Harko Senior Model V-B; Crosley Radio Corp.; (ID = 822052) Radio — Crosley Radio Corp.; Harko Senior Model V-B (1)

Harko Senior Model V-B; Crosley Radio Corp.; (ID = 822053) Radio — Crosley Radio Corp.; Harko Senior Model V-B (1)

Harko Senior Model V-B; Crosley Radio Corp.; (ID = 822054) Radio — Crosley Radio Corp.; Harko Senior Model V-B (1)

Harko Senior Model V-B; Crosley Radio Corp.; (ID = 822055) Radio — Crosley Radio Corp.; Harko Senior Model V-B (1)

Harko Senior Model V-B; Crosley Radio Corp.; (ID = 822056) Radio — Crosley Radio Corp.; Harko Senior Model V-B (1)

Harko Senior Model V-B; Crosley Radio Corp.; (ID = 822057) Radio — Crosley Radio Corp.; Harko Senior Model V-B (1)

Harko Senior Model V-B; Crosley Radio Corp.; (ID = 822064) Radio — Crosley Radio Corp.; Harko Senior Model V-B (1)

Harko Senior Model V-B; Crosley Radio Corp.; (ID = 1161830) Radio — Crosley Radio Corp.; Harko Senior Model V-B (2)

Technical Specifications

Number of Tubes
1

Valves / Tubes
UV200

Main principle
TRF with regeneration

Tuned circuits
1 AM circuit(s)

Wave bands
Broadcast only (MW).

Power type and voltage
Storage and/or dry batteries

Loudspeaker
- For headphones or amp.

Material
Wooden case

from Radiomuseum.org
Model: Harko Senior Model V-B [Regenerative made by Tri-City Electric] - Crosley Radio Corp.;

Shape
Tablemodel, Box - most often with Lid (NOT slant panel).

Notes
One dial (primary tuning control knob). Often later dated to 1923, but 1922 is evident.
First attempt to market a regenerative version. It was produced by Tresco in December 1922. Already in January 1923 Crosley bought "Precision Instrument Equipment" (ACE) to get the Armstrong license. Consequently the receivers were then sold under the ACE label which made the label Harko obsolete.
Technically this would be called the Crosley Model V-B with regular new style Adam brown mahogany cabinet, regenerative, panel marked (or die stamped letters) and sold for $17 USD in the winter of 1922. This Model V-B was also sold without regeneration for $15 USD. This info is available in the Crosley catalog page picture uploaded.

Price in first year of sale
17.00 $

Source of data
- - Manufacturers Literature

Literature/Schematics (4)
Radio Collector`s Guide 1921-1932 (Here it is named Harko Sr. only!)

Author
Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
