Transmitting Converter TC-2

Transmitting Converter TC-2; Drake, R.L. (ID = 1244600) Amateur-D Transmitting Converter TC-2; Drake, R.L. (ID = 1244601) Amateur-D
Transmitting Converter TC-2; Drake, R.L. (ID = 1244602) Amateur-D Transmitting Converter TC-2; Drake, R.L. (ID = 1244604) Amateur-D
Transmitting Converter TC-2; Drake, R.L. (ID = 1244605) Amateur-D Transmitting Converter TC-2; Drake, R.L. (ID = 1244606) Amateur-D
Use red slider bar for more.
Transmitting Converter TC-2; Drake, R.L. (ID = 1244600) Amateur-D
Drake, R.L.: Transmitting Converter TC-2 [Amateur-D] ID = 1244600 700x697
Select picture or schematic to display from thumbnails on the right and click for download.
For model Transmitting Converter TC-2, Drake, R.L. Miamisburg, Ohio

Country:  United States of America (USA)
Manufacturer / Brand:  Drake, R.L. Miamisburg, Ohio
Year: 1972 Type: Amateur Equipment (Other, but not Key)
Valves / Tubes 4: 6EJ7 6EJ7 7558 8643
Semiconductors (the count is only for transistors) 4:
Principle Converter / Adapter
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Powered by external power supply or a main unit.
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Transmitting Converter TC-2 - Drake, R.L. Miamisburg, Ohio
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 7 x 5.5 x 11 inch / 178 x 140 x 279 mm
Notes

Transmitting converter for 2 m ham band, driven by any 20 m band exciter or TR-6, oscillator injection from SC-2 converter; Pout 180 W.

Net weight (2.2 lb = 1 kg) 4 kg / 8 lb 13 oz (8.811 lb)
Price in first year of sale 378.00 $
Source of data -- Schematic
Mentioned in Katalog Hannes Bauer, 1972

Model page created by Martin Bösch. See "Data change" for further contributors.
