R4 2ème modèle, liaison BF par transformateur

Ducretet (-Thomson; avant: Fernand Ducretet et Ernest Roger etc.); Paris

  • Year
  • 1932/1933
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 37585
    • alternative name: SED

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 4
  • Number of Transistors
  • Main principle
  • TRF with regeneration
  • Tuned circuits
  • 2 AM circuit(s)
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 220 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: R4 [2ème modèle, liaison BF par transformateur] - Ducretet -Thomson; avant:
  • Shape
  • Tablemodel, high profile (upright - NOT Cathedral nor decorative).
  • Notes
  • Le récepteur R4 existe en deux versions:

    • 1° modèle avec liaison BF par résistance-capacité
    • 2° modèle avec liaison BF par transformateur

    La détection se fait à l'aide d'une triode 27 (au lieu de la 24 dans le 1er modèle) tandis que la liaison entre la détectrice et la lampe finale s'effectue par un transformateur BF.

    Le récepteur comporte une régulatrice 0.65 A, 25/75 V. Il est equipé avec un haut-parleur Thomson type 45.

  • Price in first year of sale
  • 1,750.00 FRF
  • External source of data
  • Serge Laffont/Martin Renoth
  • Literature/Schematics (2)
  • -- Original-techn. papers.
  • Literature/Schematics (3)
  • Catalogue Radio St-Lazare, 1933
