Vacuum-Tube Voltmeter Kit 221-K

Vacuum-Tube Voltmeter Kit 221-K; EICO Electronic (ID = 1460228) Equipment Vacuum-Tube Voltmeter Kit 221-K; EICO Electronic (ID = 1007101) Equipment
Vacuum-Tube Voltmeter Kit 221-K; EICO Electronic (ID = 229047) Equipment Vacuum-Tube Voltmeter Kit 221-K; EICO Electronic (ID = 1007099) Equipment
Vacuum-Tube Voltmeter Kit 221-K; EICO Electronic (ID = 1007100) Equipment
Use red slider bar for more.
Vacuum-Tube Voltmeter Kit 221-K; EICO Electronic (ID = 1460228) Equipment
EICO Electronic: Vacuum-Tube Voltmeter Kit 221-K [Equipment] ID = 1460228 933x1004
Select picture or schematic to display from thumbnails on the right and click for download.
For model Vacuum-Tube Voltmeter Kit 221-K, EICO (Electronic Instrument Co.Inc.) Brooklyn

Country:  United States of America (USA)
Manufacturer / Brand:  EICO (Electronic Instrument Co.Inc.) Brooklyn
Year: 1956 Type: Service- or Lab Equipment
Valves / Tubes 3: 6H6 6SN7 6X5
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110-130 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Vacuum-Tube Voltmeter Kit 221-K - EICO Electronic Instrument Co.
Material Metal case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 6 x 9.7 x 5 inch / 152 x 246 x 127 mm
Notes For alignment of FM and TV discriminators.
Price in first year of sale 26.00 $
Literature/Schematics (1) Allied Radio Catalog Nº 150, 1956
Literature/Schematics (2) -- Schematic

Model page created by Vitor Oliveira. See "Data change" for further contributors.
