For model Audio Generator 377, EICO (Electronic Instrument Co.Inc.) Brooklyn:
EbayCOM userbookseller_77

Country:  United States of America (USA)
Manufacturer / Brand:  EICO (Electronic Instrument Co.Inc.) Brooklyn
Year: 1955 Type: Service- or Lab Equipment
Valves / Tubes 5: 6SJ7 6K6 6SN7 6K6 6X5
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Audio Generator 377 - EICO Electronic Instrument Co.
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 7 x 11 x 7.5 inch / 178 x 279 x 191 mm
Notes Sine wave 20 Hz···200 kHz, Square wave 50 Hz···50 kHz.
Also available in kit form 377-K.
Mentioned in -- Schematic (Katalog Radio-Création (B); 1955)

Model page created by Bernd Pötzsch. See "Data change" for further contributors.
