• Year
  • 1955–1957
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 20111

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Wave bands
  • - without
  • Details
  • Record Player (not changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 220 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Miraphon 10 - Elac Electroacustic GmbH; Kiel
  • Shape
  • Chassis only or for «building in»
  • Dimensions (WHD)
  • 327 x 137 x 269 mm / 12.9 x 5.4 x 10.6 inch
  • Notes
  • 4 Geschwindigkeiten; Kristall-System KST9 mit Duplo-Nadel; Frequenzbereich 20-20000 Hz.
  • Net weight (2.2 lb = 1 kg)
  • 2.9 kg / 6 lb 6.2 oz (6.388 lb)
  • Price in first year of sale
  • 88.00 DM
  • External source of data
  • Erb

 Collections | Museums | Literature

Collections

The model Miraphon is part of the collections of the following members.

 Forum

Forum contributions about this model: Elac Electroacustic: Miraphon 10

Threads: 2 | Posts: 10

Hello,

Would anyone know where to find a 50Hz pulley, a motor with the 50Hz pulley or a parts list for this model?

Thank you,

Mike Waitz

Michael Waitz, 10.Dec.21

Weitere Posts (7) zu diesem Thema.

Hallo

Wer weiß eine Quelle für das Reibrad oder den Gummi.

Danke für eure Hilfe.

Peter Breu, 22.Dec.19

Weitere Posts (3) zu diesem Thema.
