3442

ID = 159396

Country: Spain	Manufacturer/Brand: ELBE; Barcelona
Year: 1957 ??	Type: Radio or Tuner
Valves / Tubes	5: 6BE6 6BA6 6AT6 or 6AV6 6AQ5 6X4

Principle	Super-Heterodyne (Super in general); IF-Freq. 470 kHz; 2 AF-stage(s)
Wave bands	Broadcast plus 2 Short Wave bands.
Power type and voltage	Alternating Current supply (AC) / 125 Volt
Loudspeaker/pwr.out	Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 15.2 cm = 6 inch
from Radiomuseum.org	Model: 3442

This model was suggested by Miguel Bravo-Cos.

All listed radios etc. from ELBE; Barcelona
Here you find 11 models, 1 with images and 8 with schematics.
