For model Lautsprecherchassis 124MB, Elektro-Akustik Leipzig, PGH; Leipzig (Ostd.):
RFT Datenblatt 1964
Country:  Germany
Manufacturer / Brand:  Elektro-Akustik Leipzig, PGH; Leipzig (Ostd.)
Year: 1964 Category: Loudspeaker, headphone or earphone
Wave bands - without
Power type and voltage No Power needed
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 3 W (unknown quality)
from Model: Lautsprecherchassis 124MB - Elektro-Akustik Leipzig, PGH;
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 130 x 130 x 48 mm / 5.1 x 5.1 x 1.9 inch

Rundes Breitband-Lautsprecherchassis; Impedanz: 6 Ω;  Frequenz 90...14.000 Hz.  Korb: offen, Stahlblech mit 4 Befestigungslöchern.

Bereits 1964 gefertigt, da hieß der Betrieb noch "Elektrogerätebau Leipzig" (EGB).

Ausführung mit 8 Ω bekannt.

Net weight (2.2 lb = 1 kg) 0.4 kg / 0 lb 14.1 oz (0.881 lb)
Mentioned in -- Original-techn. papers.

Model page created by Michael Mischke. See "Data change" for further contributors.
