6630 Ch= FJ-97A
| Principle |
Super-Heterodyne (Super in general); IF-Freq. 455 kHz; 2 AF-stage(s) |
| Tuned circuits |
6 AM circuit(s);
|
| Wave bands |
Broadcast and Short Wave (SW). |
| Details |
Record Player (perh.Changer) |
| Power type and voltage |
AC/DC-set / 105-125 Volt |
| Loudspeaker/pwr.out |
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
|
| from Radiomuseum.org |
Model: 6630 Ch= FJ-97A |
| Material |
Wooden case |
| Shape |
Tablemodel, with any shape - general. |
| Notes |
BC and SW (5.5 - 18 MHz) bands. Built-in loop antenna. Push-pull audio amplifier. Some models with, some without recordplayer. |
All listed radios etc. from Espey Mfg. Co., Inc.
Here you find 125 models, 27 with images and 114 with schematics.
