• Year
  • 1939
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 174553

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 4
  • Main principle
  • Superheterodyne (common); ZF/IF 452 kHz; 2 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Dry Batteries / 1.5 & 90 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Bakelite case
  • from Radiomuseum.org
  • Model: 5318 - Ever Ready Co. GB Ltd.; London
  • Shape
  • Tablemodel, high profile (upright - NOT Cathedral nor decorative).
  • Dimensions (WHD)
  • 12.5 x 12 x 8.25 inch / 318 x 305 x 210 mm
  • Notes
  • Same chassis as models 5214, 5215, & 5216. Same cabinet as the 1946 "Battery Table Model".
  • Literature/Schematics (1)
  • Trader Sheet 450
  • Author
  • Model page created by Keith Staines. See "Data change" for further contributors.
