Alldry Battery AD35
Ever Ready Co. (GB) Ltd.; London
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Ever Ready Co. (GB) Ltd.; London
- Year
- 1949 ??
- Category
- Power supply/conditioner or battery or charger
- Radiomuseum.org ID
- 119102
AD35 and B126 in a Pye "Jewel Box" P114BQ
Replica uses 2 x D cells in parallel.
Ebay pkr.relics1 321148442496
- Wave bands
- - without
- Power type and voltage
- Is a battery or storage battery / 1.5 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Various materials
- from Radiomuseum.org
- Model: Alldry Battery AD35 - Ever Ready Co. GB Ltd.; London
- Dimensions (WHD)
- 79 x 38 x 67 mm / 3.1 x 1.5 x 2.6 inch
- Notes
-
Zinc Carbon primary battery for filaments on Portable tube radio. Also known as LT (Low Tension) or A cell.
Equivalents are 1529, GEC BB405, Drydex H1184, K779, Vidor L5040, No.2D
AD means "All Dry". This may have originally been 2 x Zinc Carbon "D" cells in parallel.
About 1 Shilling & sixpence(£0.075) in late 1950s (maybe early 1960s).
- Net weight (2.2 lb = 1 kg)
- 0.255 kg / 0 lb 9 oz (0.562 lb)
- Mentioned in
- - - Manufacturers Literature (GEC Radio Battery Equivalents Table)
- Author
- Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
