GT-550

GT-550; Galaxy Electronics, (ID = 416950) Amateur GT-550; Galaxy Electronics, (ID = 416951) Amateur
GT-550; Galaxy Electronics, (ID = 416952) Amateur GT-550; Galaxy Electronics, (ID = 416953) Amateur
GT-550; Galaxy Electronics, (ID = 416954) Amateur GT-550; Galaxy Electronics, (ID = 416955) Amateur
GT-550; Galaxy Electronics, (ID = 416956) Amateur
Use red slider bar for more.
GT-550; Galaxy Electronics, (ID = 416950) Amateur
Galaxy Electronics,: GT-550 [Amateur] ID = 416950 790x450
Select picture or schematic to display from thumbnails on the right and click for download.
For model GT-550, Galaxy Electronics, Council Bluffs (IA)

Country:  United States of America (USA)
Manufacturer / Brand:  Galaxy Electronics, Council Bluffs (IA)
Year: 1970 Category: Amateur Transmitter/Receiver (and Transceiver)
Valves / Tubes 11: 12BZ6 6HG8 6KE8 6EW6 12BA6 6GX6 12AT7 6EJ7 6GK6 6LB6 6LB6
Semiconductors (the count is only for transistors) 16:
Main principle Superhet with RF-stage; ZF/IF 9000 kHz
Wave bands Short Wave (SW only)
Details
Power type and voltage Powered by external power supply or a main unit.
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: GT-550 - Galaxy Electronics, Council
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 285 x 152 x 316 mm / 11.2 x 6 x 12.4 inch
Notes SSB/CW - transceiver for 80-10 m HAM-bands, Input power SSB 550 watts, CW 360 watts; needs speaker with built in power supply CS550
Net weight (2.2 lb = 1 kg) 7.7 kg / 16 lb 15.4 oz (16.96 lb)
Price in first year of sale 2,450.00 DM
Collectors' prices
Source of data -- Original prospect or advert

Model page created by Herbert Heintges. See "Data change" for further contributors.



All listed radios etc. from Galaxy Electronics, Council Bluffs (IA)
Here you find 12 models, 12 with images and 2 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
