AM FM Television Receiver 12TZ Series 12TZ2

Garod Radio Corp.; Brooklyn (NY)

  • Year
  • 1949 ?
  • Category
  • Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
  • Radiomuseum.org ID
  • 234536

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 29
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 105-125 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: AM FM Television Receiver 12TZ Series 12TZ2 - Garod Radio Corp.; Brooklyn NY
  • Shape
  • Tablemodel, with any shape - general.
  • Notes
  • AM FM Television Receiver 12TZ2. Tuning ranges: AM 540 - 1650 kc, FM 88 - 108 Mc, TV channels 2 thru 13.

    This set is equipped with a 12" picture tube, different types are possible.

  • Literature/Schematics (1)
  • Rider's TV, 3-1
