GE-83

General Electric Co. (GE); Bridgeport CT, Syracuse NY

Data
Forum
Pictures
Collections

  • Year
  • 1938 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 284704
    • Brand: Musaphonic

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 7
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz
  • Wave bands
  • Broadcast, Long Wave and Short Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / Either Transformer Tap: 50 to 60Hz, 115 to 120V or 140 to 155V or 190 to 220V or 220 to 250 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm
  • Power out
  • 2.5 W (5 W max.)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: GE-83 - General Electric Co. GE;
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 25 x 14.5 x 9 inch / 635 x 368 x 229 mm
  • Notes

  • The General Electric GE-83 is an AC operated 7 tube LW, BC and SW receiver. Uses Qty(2) #46 dial lamps. Has 4 position tone control.  Also has 8 to 1 fast tuning and 40 to 1 fine tuning control.

    Band Frequency Ranges are as follows:
    LW Band ("A" Band).............140 - 400 kHz
    BC Band ("B" Band)..............540 - 1600 kHz
    SW Band ("D" Band).............6.0 - 18.0 MHz

  • Author
  • Model page created by John Kusching. See "Data change" for further contributors.
