JFM-165

JFM-165 ; General Electric Co. (ID = 1131465) Radio

JFM-165 ; General Electric Co. (ID = 1131467) Radio

JFM-165 ; General Electric Co. (ID = 169976) Radio
JFM-165 ; General Electric Co. (ID = 163447) Radio JFM-165 ; General Electric Co. (ID = 379577) Radio
JFM-165 ; General Electric Co. (ID = 379582) Radio JFM-165 ; General Electric Co. (ID = 379578) Radio
JFM-165 ; General Electric Co. (ID = 379580) Radio JFM-165 ; General Electric Co. (ID = 1396304) Radio
JFM-165 ; General Electric Co. (ID = 707374) Radio
Use red slider bar for more.
JFM-165 ; General Electric Co. (ID = 163447) Radio
General Electric Co.: JFM-165 [Radio] ID = 163447 370x522
Select picture or schematic to display from thumbnails on the right and click for download.
For model JFM-165, General Electric Co. (GE); Bridgeport CT, Syracuse NY

Country:  United States of America (USA)
Manufacturer / Brand:  General Electric Co. (GE); Bridgeport CT, Syracuse NY
Brand

Musaphonic
Year: 1940–1942 Type: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 16: 6AB7 6AB7 7A4 6SK7 6SK7 6SJ7 6SJ7 6H6 5Y3G 6SK7 6SA7 6SK7 6SQ7 6J5G 6Y6G 5Y3G
Principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Wave bands Broadcast, 2 Short Wave plus FM.
Details
Power type and voltage Alternating Current supply (AC) / 105-125 Volt
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet. / Ø 14 inch = 35.6 cm
Power out 4 W (unknown quality)
from Radiomuseum.org Model: JFM-165 - General Electric Co. GE;
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Dimensions (WHD) 31.3 x 41.5 x 16.2 inch / 795 x 1054 x 411 mm
Notes

2 Chassis.

Collectors' prices
External source of data Ernst Erb
Source of data The Radio CollectorGrinder, 1995
Circuit diagram reference Rider's Perpetual, Volume 14 = 1944 = before 1943
Mentioned in Pre-War Consoles; Stein, 2000
Literature/Schematics (1) General Electric Radio Service Notes 1939-1942
Literature/Schematics (3) General Electric Folder 13-497-W for 1941.

All listed radios etc. from General Electric Co. (GE); Bridgeport CT, Syracuse NY
