For model 2041PW EC92, Grundig (Radio-Vertrieb, RVF, Radiowerke):
2041PW

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1953 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: EC92 ECH81 EF93 EABC80 EM85 EL41
schematic requested
Main principle Super-Heterodyne (Super in general)
Tuned circuits 6 AM circuit(s)     8 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker
Power out
from Radiomuseum.org Model: 2041PW [EC92] - Grundig Radio-Vertrieb, RVF,
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 550 x 350 x 220 mm / 21.7 x 13.8 x 8.7 inch
Notes





Model page created by Alberto Mengual. See "Data change" for further contributors.
