• Year
  • 1970 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 256672
    • alternative name: Grundig Portugal || Grundig USA / Lextronix

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common); Export model
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Power type and voltage
  • Dry Batteries / 2 x 4,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Power out
  • 2.5 W (undistorted)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Elite-Boy 210E - Grundig Radio-Vertrieb, RVF,
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 300 x 175 x 80 mm / 11.8 x 6.9 x 3.1 inch
  • Notes
  • Exportgerät, gleicher Aufbau wie Elite Boy 210.
    Autobetrieb über Taste schaltbar; Koax-Anschluß für Autoantenne; Lichttaste; Instrument-Batterieanzeige; Anschlußmöglichkeit für Tonband oder Plattenspieler und ext. Netzgerät (9 Volt).

  • Net weight (2.2 lb = 1 kg)
  • 2.2 kg / 4 lb 13.5 oz (4.846 lb)

 Collections | Museums | Literature

Collections

The model Elite-Boy is part of the collections of the following members.

 Forum

Forum contributions about this model: Grundig Radio-: Elite-Boy 210E

Threads: 1 | Posts: 4

Ich habe einen EliteBoy bekommen. Er funktioniert jetzt soweit, nur ist das Skalenseil mit Zeiger und alle 4 Umlenkröllchen  nicht vorhanden.  Es sind dies Rollen mit ca. 5mm Durchmesser ( geschätzt, gesehen hab ich noch keine!) Loch für die  Achse ist  1,5mm.  Wer sowas herumliegen hat, ist herzlich eingeladen, mir ein Mail zu schicken.

Seilzüge hab ich genug und Zeiger ist auch kein Problem, nur Röllchen hab ich keine.

Danke fürs Nachschauen!

LG

Karl Reiter

Hat sich erledigt, ein Freund hat mir 4 Röllchen aus Kunststoff gedreht.

K. Reiter

Karl Reiter, 04.Jul.18
