• Year
  • 1962–1965
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 25964
    • alternative name: Grundig Portugal || Grundig USA / Lextronix

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Tape Recorder
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 130; 220; 240 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Power out
  • 7 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: TK41K - Grundig Radio-Vertrieb, RVF,
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 550 x 185 x 370 mm / 21.7 x 7.3 x 14.6 inch
  • Notes
  • Technische Daten wie TK41, jedoch robuster Stahlblechkoffer und Umschaltmöglichkeit der Stromversorgung zwischen 50 und 60 Hz.
  • Net weight (2.2 lb = 1 kg)
  • 17.8 kg / 39 lb 3.3 oz (39.207 lb)
  • Price in first year of sale
  • 848.00 DM
  • External source of data
  • Erb
