• Year
  • 1972/1973
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 154636
    • alternative name: Grundig Portugal || Grundig USA / Lextronix

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 23
  • Semiconductors
  • Main principle
  • Superhet, double/triple conversion; ZF/IF 460/1850/10700 kHz
  • Tuned circuits
  • 13 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
  • Power type and voltage
  • Line / Batteries (any type) / 110-127; 220-240 / 6 x 1,5 Volt
  • Loudspeaker
  • 2 Loudspeakers
  • Power out
  • 2 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Transistor TR 6002 - Grundig Radio-Vertrieb, RVF,
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 440 x 260 x 130 mm / 17.3 x 10.2 x 5.1 inch
  • Notes
  • 17 KW-Bereiche von 10 bis 180 m.
    Exportversion des Satellit 1000.
    Transistor TR-6002 is the export version of Satellit 1000.

  • Net weight (2.2 lb = 1 kg)
  • 7 kg / 15 lb 6.7 oz (15.419 lb)
  • Literature/Schematics (1)
  • -- Original-techn. papers.
