Videogenerator VG1100

• Country
• Germany

• Manufacturer / Brand
• Grundig (Radio-Vertrieb, RVF, Radiowerke)

• Year
• 1995 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 208304

• • alternative name: Grundig Portugal || Grundig USA / Lextronix

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110; 220; 240 Volt

• Material
• Metal case

• from Radiomuseum.org
• Model: Videogenerator VG1100 - Grundig Radio-Vertrieb, RVF,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 300 x 113 x 227 mm / 11.8 x 4.4 x 8.9 inch

• Notes
• Grundig Electronic Videogenerator VG1100;
  FuBK Testbild, YCbCr Komponenten Generator, RGB Signale, YC Signale,
  mit weißer oder dunkler Frontblende.
  Bekannte Optionen:
  Option G.UE 70-01: PAL (B, D, G, H, I, M, N) und NTSC (3.58 und 4.43 MHz)
  Option G.UE 70-03: SECAM
  Option G.UE 70-04: Component (Option with RGB)
  Option G.UE 70-05: Videotext und VPS
  Option G.UE 70-06: Fernbedienbarkeit über IEEE 488
  Option G.UE 36-02: 19" Adapter, 40 VA power consumption.

• Net weight (2.2 lb = 1 kg)
• 8 kg / 17 lb 9.9 oz (17.621 lb)

• Source of data
• - - Manufacturers Literature

• Author
• Model page created by a member from A. See "Data change" for further contributors.

• Other Models

• Here you find 6196 models, 5420 with images and 4190 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Grundig (Radio-Vertrieb, RVF, Radiowerke)
