The New Englander Stereophonic 921ML

• Country
• United States of America (USA)

• Manufacturer / Brand
• Guild Radio & Television Co.; Inglewood (CA)

• Year
• 1965

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 200475

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 20

• Valves / Tubes
• ECC83 ECC83 6BA6 6AU6 6AU6 6AL5 6BA6 6BE6 6BA6 12AU7 12AX7 12AU7 12AU7 12AU7 12AU7 6BQ5 6BQ5 6BQ5 6BQ5 5U4GB

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Loudspeaker
• 5 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: The New Englander Stereophonic 921ML - Guild Radio & Television Co.;

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 39 x 43 x 0 inch / 991 x 1092 x 0 mm

• Notes

• Guild "The New Englander" Stereophonic model 921ML.
  Desktop shaped console, separate AM & FM tuning, split chassis, stereo balance meter.

• Author
• Model page created by a member from A. See "Data change" for further contributors.
