• Year
  • 1964
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 82742

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 11
  • Valves / Tubes
  • 5UP1
  • Power type and voltage
  • Alternating Current supply (AC) / 60Hz, 120 Volt
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Oscilloscope HOW-1 - Hallicrafters, The; Chicago,
  • Shape
  • Tablemodel, with any shape - general.
  • Notes
  • 5" Oscilloscope with vertical bandwidth of 5 MHz, horizontal response is 4 Hz to 400 kHz with a sensitivity of 120 mV/cm, rise time of 0.08 microseconds, also available as a kit called HO-1 priced at 85 USD.
  • Price in first year of sale
  • 165.00 $
  • Author
  • Model page created by a member from D. See "Data change" for further contributors.
