SX-122 (SX122)
ID = 79447
 |
 |
 |
 |
| Country: United States of America (USA) | Manufacturer/Brand: Hallicrafters, The; Chicago (IL) |
| Year: 1962 – 1966 | Type: Communication Receiver (also Amateur) |
| Valves / Tubes | 10: 6DC6 6AU6 6C4 6DC6 6BL8 6BA6 6BE6 6BN8 6GW8 0A2 5Y3 |
|---|
| Principle | Superhet, double/triple conversion; IF-Freq. 1650 kHz |
|---|---|
| Wave bands | Broadcast plus more than 2 Short Wave bands. |
| Power type and voltage | Alternating Current supply (AC) / 105-125 Volt |
| Loudspeaker/pwr.out | - For headphones or amp. / 1 W |
| from Radiomuseum.org | Model: SX-122 |
| Material | Metal case |
| Shape | Tablemodel, low profile (big size). |
| Dimensions (WHD) | 476 x 248 x 203 mm / 18.7 x 9.8 x 8 inch |
| Notes | Coverage: 0.538-1.58, 1.72-4.9, 4.6-13, 12-34MHz, reception gap from 1.58-1.72MHz, 2nd IF 50KHz, 50KHz L/C Filter, 1 SI-Diode. |
This model was suggested by Martin Renoth.
