Citation Eleven (11)

Citation Eleven ; Harman Kardon; New (ID = 273471) Ampl/Mixer Citation Eleven ; Harman Kardon; New (ID = 1598071) Ampl/Mixer
Citation Eleven ; Harman Kardon; New (ID = 1598081) Ampl/Mixer
Use red slider bar for more.
Citation Eleven ; Harman Kardon; New (ID = 273471) Ampl/Mixer
Harman Kardon; New: Citation Eleven [Ampl/Mixer] ID = 273471 640x226
Select picture or schematic to display from thumbnails on the right and click for download.
For model Citation Eleven (11), Harman Kardon; New York

Country:  United States of America (USA)
Manufacturer / Brand:  Harman Kardon; New York
Year: 1968 ?? Type: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) 13:
Details Hi-Fi equipment
Power type and voltage Alternating Current supply (AC) / 110-220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Citation Eleven - Harman Kardon; New York
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 400 x 130 x 300 mm / 15.7 x 5.1 x 11.8 inch
Notes

Stereophonic preamplifier and audio equalizer of professional quality.
High cut filter -8 dB at 10000Hz.
Subsonic filter -12 dB at 15 Hz.
5 Band audio equalizer ±12 dB at 60 Hz / 320 Hz / 1 kHz / 5kHz / 12kHz.
Audio output into 10000 ohm = up to 6 volt RMS.
Matching power amp Citation twelve.

Mentioned in -- Original-techn. papers.

Model page created by Giuseppe Antonio Tusini. See "Data change" for further contributors.
