Studio 9000 automatic

HEA; Wien

  • Year
  • 1976
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 62793

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 39
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 10700 kHz
  • Wave bands
  • FM Broadcast Band Only
  • Details
  • Record Player (not changer); Hi-Fi equipment
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 80 W (undistorted)
  • Material
  • Various materials
  • from Radiomuseum.org
  • Model: Studio 9000 automatic - HEA; Wien
  • Shape
  • Tablemodel, low profile (big size).
  • Notes
  • Transistoren und IC . Mit FM-Stereo Tuner ta 2

    4 UKW Senderspeicher
    4 Lautsprecher Anschlüsse
    2 Kopfhörer Anschlüsse
    Lenco Plattenspieler L84

    Siehe auch baugleiches Gerät ohne Plattenspieler: HEA Studio 9002

  • Source of data
  • Radiokatalog Band 2, Ernst Erb
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Gerhard Heigl. See "Data change" for further contributors.
