Trixi UKW UKW MW LW

HEA; Wien

  • Year
  • 1961/1962
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 8561

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 9
  • Main principle
  • Superheterodyne (common); ZF/IF 461/10600 kHz
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Power type and voltage
  • Dry Batteries / 2 x 4,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Leather / canvas / plastic - over other material
  • from Radiomuseum.org
  • Model: Trixi UKW [UKW MW LW] - HEA; Wien
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 228 x 165 x 85 mm / 9 x 6.5 x 3.3 inch
  • Notes
  •

    Gewicht ohne Batterien

  • Net weight (2.2 lb = 1 kg)
  • 1.6 kg / 3 lb 8.4 oz (3.524 lb)
  • External source of data
  • E. Erb 3-907007-36-0
  • Source of data
  • Radiokatalog Band 2, Ernst Erb
  • Literature/Schematics (1)
  • -- Original-techn. papers.

 Collections | Museums | Literature

 Forum

Forum contributions about this model: HEA; Wien: Trixi UKW

Threads: 1 | Posts: 1

Orig.Preis: 1680S, Betrieb: 2x4,5V Flachbatt., Gehäuse: Kunststoff, BHT: 230x160x80mm, Transistoren:2xAF114, 3xAF116, OC75, OC71, 2xOC74.

Gerhard Heigl, 17.Jul.02

Weitere Posts (1) zu diesem Thema.
