VFO HG-10B

VFO HG-10B; Heathkit Brand, (ID = 159270) Amateur-D

VFO HG-10B; Heathkit Brand, (ID = 159272) Amateur-D

VFO HG-10B; Heathkit Brand, (ID = 159274) Amateur-D
VFO HG-10B; Heathkit Brand, (ID = 768633) Amateur-D VFO HG-10B; Heathkit Brand, (ID = 768635) Amateur-D
VFO HG-10B; Heathkit Brand, (ID = 768636) Amateur-D VFO HG-10B; Heathkit Brand, (ID = 751807) Amateur-D
VFO HG-10B; Heathkit Brand, (ID = 751805) Amateur-D VFO HG-10B; Heathkit Brand, (ID = 751806) Amateur-D
VFO HG-10B; Heathkit Brand, (ID = 751808) Amateur-D VFO HG-10B; Heathkit Brand, (ID = 768634) Amateur-D
VFO HG-10B; Heathkit Brand, (ID = 1169132) Amateur-D
Use red slider bar for more.
VFO HG-10B; Heathkit Brand, (ID = 768633) Amateur-D
Heathkit Brand,: VFO HG-10B [Amateur-D] ID = 768633 933x652
Select picture or schematic to display from thumbnails on the right and click for download.
For model VFO HG-10B, Heathkit (Brand), Heath Co.; Benton Harbor (MI):
Ebay 320532300741

Country:  United States of America (USA)
Manufacturer / Brand:  Heathkit (Brand), Heath Co.; Benton Harbor (MI)
alternative name

Heath Company
Year: 1962–1976 ? Type: Amateur Equipment (Other, but not Key)
Valves / Tubes 1: 6CH8 0B2
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Powered by external power supply or a main unit.
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: VFO HG-10B - Heathkit Brand, Heath Co.;
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 9.75 x 6.5 x 9.12 inch / 248 x 165 x 232 mm
Notes Heathkit External VFO HG-10B. Range 80-2 meter for DX-60 series. Output frequency ranges: 3.5-4, 7-7.425, 8.333-9 & 8-8.222MHz. First model HG-10 advertised in 1962.
Net weight (2.2 lb = 1 kg) 5.5 kg / 12 lb 1.8 oz (12.115 lb)
Price in first year of sale 38.00 $
Collectors' prices
Source of data Heathkit-A guide-Chuck Penson
Literature/Schematics (1) -- Schematic

Model page created by Hinrich Grensemann. See "Data change" for further contributors.
